6.35
Screw-cage connection
300
30
30-10
630
32
0.2-6.0
▎Technical Data
Model Item
GT636A-6.35
Type
PCB Screw Terminal Block
Pitch (mm)
6.35 mm
No.of Poles
2*(2-24)
UL
Rated voltage(B)
300V
Rated current(B)
30A
Torque Value (Lb,in)
7.02Lb.in
Connection range(AWG)
30-10AWG
IEC
Rated voltage(IEC)
630V
Rated current(IEC)
32A
Torque Value (N.m)
0.8N.m
Rigid conductor size(mm²)
0.2-6mm²
Flexible conductor size(mm²)
Item properties
Stripping length
7-8mm
Ambient Temperature
-40℃~+105℃
Wire connection direction
0°
Connection Technology
Screw connection
Screw thread
M3.5
Material
Insulation material
PA66, UL94V-0
Contact material
Copper alloy.
Conductor surface plating
Sn plated
