▎Product Advantage
Made from 100% new PA66/PBT plastics and good stainless steel, with heat-treated, zinc-plated carbon steel screws, ensuring excellent insulation, corrosion resistance, and long-term mechanical reliability.
High-grade steel molds with QR codes and unique IDs enable traceability and consistent dimensions, ensuring uniform quality across all terminal blocks.
High-precision injection molding and automated assembly with 8-camera CCD inspection ensure 100% of products meet strict quality standards.
Rigorous first-sample, in-process, and final inspections, including glow-wire and drop tests, guarantee electrical safety and durability.
Samples are produced on the same lines as mass orders, ensuring identical materials, processes, and performance.
Used in 25+ countries with zero quality complaints in Europe over 10 years.
▎Technical Parameters
Electrical Specifications |
Model | GT126-5.0-XXP-XX-00 |
Standard | UL | IEC |
Rated Voltage | 300V | 250V |
Rated Current | 10A | 18A |
Wire Range | 26-14AWG | 0.5-2.5mm² |
Torque Value | M2.5, 3.54Lb.in M2.5, 0.4N.M |
Poles | 2-24P |
Stripping Length | 5-6mm |
Withstanding Voltage | AC2000V/1Min |
Operating Temperature | -40℃~+105℃ |
Housing | PA66, UL94V-0 |
Screw | M2.5 Steel, Zn Plated |
Contact | Copper Alloy, Tin Plated |
Spring | Stainless Steel |
▎Product Uses
Screw terminals provide secure, stable connections for reliable wiring in modular control panels.
They ensure dependable connections for sensors, controllers, and actuators while supporting maintenance and upgrades.
Screw terminals improve wiring efficiency, reduce errors, and support modular equipment design.
They offer vibration-resistant, safe connections for trains, EVs, and signaling systems.
Screw terminals enable reliable multi-circuit connections, simplifying installation and maintenance in energy systems.
▎FAQ
Q1: Can I get a sample?
A: Yes, we are happy to provide free samples. However, the shipping cost will need to be covered by the customer.
Q2: What is the lead time?
A: For standard product samples, the lead time is 1–2 days. For mass production, it typically takes 1–2 weeks. For orders exceeding 100,000 pieces, please contact us for a specific delivery schedule.
Q3: What is the minimum order quantity (MOQ)?
A: Our standard MOQ is 500 pieces. For customized products, the MOQ will be evaluated based on the specific requirements.
