GT166-5.0

Model Item

GT166-5.0

Type

PCB Screw Terminal Block

Pitch (mm)

5.0mm

No.of Poles

2-12

UL

Rated voltage(B)

300V

Rated current(B)

15A

Torque Value (Lb,in)

4.4Lb.in

Connection range(AWG)

22~12AWG

IEC

Rated voltage(IEC)

250V

Rated current(IEC)

22A

Torque Value (N.m)

0.5N.m

Rigid conductor size(mm²)

1.0~2.5mm²

Flexible conductor size(mm²)

1.0~2.5mm²

Item properties

Stripping length

7mm

Ambient Temperature

-40℃~+105℃

Wire connection direction

0°

Connection Technology

Screw connection

Screw thread

M3

Material

Insulation material

PA66, UL94V-0

Contact material

Copper alloy.

Conductor surface plating

Sn plated
